Image of PENGARUH VARIASI PANJANG POROS DAN JUMLAH MASSA TERHADAP PUTARAN KRITIS POROS PADA PENGUJIAN WHIRLING SHAFT

Tugas Akhir Mesin

PENGARUH VARIASI PANJANG POROS DAN JUMLAH MASSA TERHADAP PUTARAN KRITIS POROS PADA PENGUJIAN WHIRLING SHAFT

Very many application of a rotating shaft in a machining construction. The shaft that functions to transmit the power supplied from one component to another component is always happened rotational motion. The biggest curvature that occurs on the rotating shaft is caused when a critical speed occurs (critical speed), this phenomenon is called the whirling effect. Therefore, in this research will be to design a tool to get round the critical speed of a rotating shaft. This research was conducted with an experimental method using a critical speed test. In this critical speed tool will be tested with some the length axis variation and the masses numbers (disc) that be assembled on the shaft between the two bearings and then rotated using an electric motor and the critical round value in the experimental method will be validated with theoretical calculations. The test uses a 12 volt DC motor with a maximum round (n) of 3000 rpm and a critical speed engine test equipment on a 304 stainless steel shaft rod with a diameter of D = 12 mm with a maximum length of shaft L = 600 mm. The test will be carried out using the Arduino controller with the PID algorithm. In other words, the critical speed will be faster when the shaft is getting longer. The smallest difference in the length of shaft variations experimenal and theoretically by ignoring the number of mass there is a comparison of 1.193%. While the smallest difference in the number of mass variations in experimental and theoretically ignoring the length of a comparison of 17.958%.

Ketersediaan
2019272621.8.Put.pTersedia
Informasi Detail
Judul Seri
-
No. Panggil
621.8.Put.p
Penerbit
Universitas Mataram : Fakultas Teknik Unram.,
Deskripsi Fisik
xiii;44 Hlm; Illus; 21x29 cm
Bahasa
Indonesia
ISBN/ISSN
-
Klasifikasi
621.8
Tipe Isi
other
Tipe Media
computer
Tipe Pembawa
audio disc
Edisi
Edisi 1
Subjek
konstruksi pemesinan
Com shaft, disc, deflection, maximum round, critic
